The new TD-9 sound module is loaded with fresh sounds, and offers a deeper level of expression. Together with Roland’s most advanced triggering technology, this kit is destined to become a big hit with drummers worldwide.
Advanced TD-9 module with expressive new sounds, real-audio songs and patterns
Comfortable mesh-head tom and snare pads with rim triggering
Three-way triggering for ride cymbal
Scope function with graphical LCD display
USB host for audio-file (.WAV) playback
Special cable for easy pad connections
Sturdy drum rack (MDS-9) with newly designed ball-clamps for the snare and cymbal arms and a new hi-hat mount for maximum flexibility
TD-9 Percussion Sound Module x 1 |
PD-105BK V-Pad (za doboš) x 1 |
PD-85BKV-Pad (za tom) x 3 |
CY-5 Dual-Trigger Cymbal Pad x 1 |
CY-8 Dual-Trigger Cymbal Pad x 1 |
CY-12R/CV-Cymbal Ride/Crash x 1 |
KD-8 Kick Trigger Pad x 1 |
FD-8 Hi-Hat Control Pedal x 1 |
MDS-9 stalak x 1 |
Stalak i kick pedala ne ulaze u cenu kompleta |
TD-9 podržava triggering okvira na V-Padovima za tomove i 3 načina triggeringa za Ride. |
Instruments
Drum Instruments:522
Drum Kits
50
Instrument Parameters
KICK: Head Tuning, Muffling
SNARE: Head Tuning, Muffling
TOM: Head Tuning, Muffling
HI-HAT: Cymbal Size, Fixed Hi-Hat
CYMBAL: Cymbal Size, Sustain
OTHERS: Pitch, Decay
Effect Types
Ambience (9 types), 2-Band Equaliser
Ambience Parameters
Room Type, Room Size, Wall Type, Mic Position, Room Shape
Mixer Parameters
Volume, Pan
Percussion Set
1
Song
Preset Songs: 50
Parts: 4
Play Function: One shot, Loop, Repeat
Tempo: 20-300
Quick Rec
Resolution: 480 ticks per quarter note
Recording Method: Real-time
Maximum Note Storage: Approx. 32,000 Notes
Audio File Format
WAV
Display
128 x 64 dots Graphic Type LCD (backlit LCD)
Connectors
Trigger Cable connector (DB-25 type), (Kick, Snare, Tom 1, Tom 2, Tom 3, Hi-Hat, Crash 1, Ride, Ride Bell, Hi-Hat Control), Extra Trigger Input Jacks: 2 (CRASH2, AUX) (Stereo 1/4 inch phone type), Output Jacks (L (MONO), R) (Stereo 1/4 inch phone type), Phones Jack (Stereo 1/4 inch phone type), Mix in Jack (Stereo miniature phone type), MIDI Connectors (IN, OUT/THRU), USB Connector (for USB Memory)
Output Impedance
1.0 k ohms
Power Supply
AC Adaptor (DC 9V)
Current Draw
500 mA
Accessories
Owner's Manual, Quick Start Guide, AC Adaptor (PSB-1U), Special Connection Cable, Wing Bolt (M5 x 10) x 2, Sound Module Mounting Plate
Options
Cymbal Mount (MDY-10U), Pad Mount (MDH-10U), Personal Drum Monitor (PM-10, PM-30), V-Drums Accessory Package (DAP-3), V-Drums Mat (TDM-10)
Size and Weight
Width
1,300 mm
51-3/16 inches
Depth
1,200 mm
47-1/4 inches
Height
1,350 mm
53-3/16 inches
Weight
15.0 kg
33 lbs. 2 oz.
