| SPECIFICATIONS |
| Sampling Frequency |
| 44.1 kHz |
| AD/DA Conversion |
| 32 bits |
| Processing |
| 32-bit floating point |
| Recording/Playback |
| Number of Track: 1 |
| Data Format: WAV (44.1 kHz, 32-bit float, stereo) |
| Maximum Recording Time: Approx. 1.5 hours (1 track), Approx.13 hours (total of All memories) |
| Rhythm Type |
| 57 Patterns x 2 Variations |
| Rhythm Kit |
| 7 types |
| Effect |
| Reverb (only for rhythm part) |
| Memory |
| 99 |
| Nominal Input Level |
| INPUT A/MONO, B: -20 dBu |
| Input Impedance |
| INPUT A/MONO, B: 1 M ohm |
| Nominal Output Level |
| OUTPUT A/MONO, B:-20 dBu |
| Output Impedance |
| OUTPUT A/MONO, B: 1 k ohm |
| Recommended Load Impedance |
| OUTPUT A/MONO, B: 10 k ohms or greater |
| Bypass |
| Buffered bypass |
| Controls |
MEMORY/LOOP LEVEL knob, MEMORY button, SETUP button, RHYTHM ON/OFF button,
RHYTHM TEMPO button, Pedal switch |
| Display |
| Graphic LCD (96 x 32 dots, RGB backlit LCD) |
| Connectors |
| INPUT A/MONO, B jacks: 1/4-inch phone type |
| OUTPUT A/MONO, B jacks: 1/4-inch phone type |
| STOP/MEMORY jack: 1/4-inch TRS phone type |
| USB port: USB B type |
| MIDI (IN, OUT) jacks: stereo miniature type |
| DC IN jack |
| Power Supply |
| Alkaline battery (9 V, 6LR61 or 6LF22) |
| AC adaptor (PSA series: sold separately) |
| Current Draw |
| 170 mA |
| Expected battery life under continuous use |
| Alkaline: Approx. 2 hours |
| *These figures will vary depending on the actual conditions of use. |
| Accessories |
| Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTES," and "Information") |
| Alkaline battery (9 V, 6LR61 or 6LF22) |
| Options (sold separately) |
| AC adaptor: PSA-S series |
| Footswitch: FS-5U |
| Dual Footswitch: FS-6, FS-7 |
| Expression Pedal: FV-500H, FV-500L, EV-30, Roland EV-5 |
| TRS/MIDI connecting cable: BMIDI-5-35, BMIDI-1-35, BMIDI-2-35, BCC-1-3535, BCC-2-3535 |
| SIZE AND WEIGHT |
| Width |
| 73 mm |
| 2-7/8 inches |
| Depth |
| 129 mm |
| 5-1/8 inches |
| Height |
| 56 mm |
| 2-1/4 inches |
| Weight (including battery) |
| 450 g |
| 1 lb |
| * 0 dBu = 0.775 Vrms |
| *The specifications are subject to change without notice. |
