THE RN17 REDEFINES THE CAPABILITIES OF SMALL-DIAPHRAGM CONDENSERS
The second product of the sE / Rupert Neve collaboration, work on the RN17 began with a discussion between Rupert and Siwei Zou on the merits and problems of small-diaphragm condensers.
Specs
Components
Capsule
Hand-crafted 2/3" True Condenser
Power
Electrical impedance
200 Ohms
Connectivity
3-pin male XLR connector
Powering
48V Phantom Power (P48 according to IEC 61938)
Sound
Polar patterns
Cardioid (Omnidirectional capsule available separately)
Frequency range
20 Hz - 20 kHz
Sensitivity
6 mV / Pa (-44.5 dBV)
Sensitivity (Figure-8)
2.5 mV / Pa (-52 dBV)
Max SPL
131 dB (0.5% THD @ 1kHz)
Equivalent noise level
18 dB (Cardioid), 15 dB (Omni)
Signal to noise ratio
76 dB
Dimensions
Mic length
200 mm (7.87 in.)
Diaphragm
17.2 mm gold / mylar
What's in the box
RN17 microphone
Custom shock-mount
Wooden box
Metal case
Thread adapter
User manual
