Dimensions |
Width |
1,336 mm [52-5/8"] |
|
|
Height |
145 mm [5-11/16"] (with music rest: 328 mm [12-15/16"]) |
|
|
Depth |
376 mm [14-13/16"] (with music rest: 403 mm [15-7/8"]) |
|
|
Weight |
Weight |
22.0 kg [48 lb, 8 oz] |
|
|
Dimensions (with optional stand) |
Width |
1,336 mm [52-5/8"] |
|
|
Height |
757 mm [29-13/16"] (with music rest: 939 mm [37-0"]) |
|
|
Depth |
377 mm [14-13/16"] (with music rest: 402 mm [15-13/16"]) |
|
|
Dimensions of Packing Box |
W x H x D |
1,457 mm x 311 mm x 531 mm [57-3/8" x 12-1/4" x 20-7/8"] |
|
|
Control Interface |
Keyboard |
Number of Keys |
88 |
|
|
Type |
GrandTouch-S™ Keyboard: wooden keys (white only), synthetic ebony and ivory key tops, escapement |
|
|
Touch Sensitivity |
Hard2/Hard1/Medium/Soft1/Soft2/Fixed |
|
|
Pedal |
Number of Pedals |
3 (when using the pedal unit, LP-1/FC35) |
|
|
Assignable Functions |
Sustain (Switch), Sustain (Continuous), Sostenuto, Soft, Pitch Bend Up, Pitch Bend Down, Rotary Speed, Vibe Rotor, Song Play/Pause |
|
|
Display |
Type |
Full Dots LCD |
|
|
Size |
198 x 100 dots |
|
|
Language |
English, Japanese |
|
|
Panel |
Language |
English |
|
|
Voices |
Tone Generator |
Piano Sound |
Yamaha CFX, Bösendorfer Imperial |
|
|
Binaural Sampling |
Yes ("CFX Grand" Voice only) |
|
|
Virtual Resonance Modeling (VRM) |
Yes |
|
|
Grand Expression Modeling |
Yes |
|
|
Key-off Samples |
- |
|
|
Damper Resonance |
- |
|
|
Polyphony (max.) |
256 |
|
|
Preset |
Number of Voices |
44 Voices + 18 Drum/SFX Kits + 480 XG Voices |
|
|
Compatibility |
XG (GM), GS (for Song playback), GM2 (for Song playback) |
|
|
Effects |
Types |
Reverb |
7 types |
|
|
Chorus |
3 types |
|
|
Master EQ |
3 Preset + 1 User |
|
|
Insertion Effect |
12 types |
|
|
Intelligent Acoustic Control (IAC) |
Yes |
|
|
Stereophonic Optimizer |
Yes |
|
|
Sound Boost |
3 types |
|
|
Wall EQ |
- |
|
|
Functions |
Dual/Layers |
Yes |
|
|
Split |
Yes |
|
|
Duo |
Yes |
|
|
Songs |
Preset |
Number of Preset Songs |
21 Voice Demo Songs + 50 Classics |
|
|
MIDI Recording |
Number of Songs |
250 |
|
|
Number of Tracks |
16 |
|
|
Data Capacity |
Approx. 500 KB/Song (approx. 22,000 notes) |
|
|
Audio Recording (USB memory) |
Recording Time (max.) |
80 minutes/Song |
|
|
Compatible Data Format |
Playback |
SMF (Format 0, Format 1), WAV (44.1 kHz sample rate, 16-bit resolution, stereo) |
|
|
Recording |
SMF (Format 0), WAV (44.1 kHz sample rate, 16-bit resolution, stereo) |
|
|
Functions |
Piano Room |
Yes |
|
|
Rhythm |
Number of Rhythms |
40 |
|
|
Registration Memory |
Number of Buttons |
6 (x 4 banks) |
|
|
Overall Controls |
Metronome |
Yes |
|
|
Tempo Range |
5 - 500 |
|
|
Transpose |
-24 |
|
|
Tuning |
414.8 - 440.0 - 466.8 Hz (approx. 0.2 Hz increments) |
|
|
Scale Type |
7 types |
|
|
USB Audio Interface |
44.1 kHz, 24 bit, stereo |
|
|
Bluetooth |
Audio/MIDI (varies by area) |
|
|
Storage and Connectivity |
Storage |
Internal Memory |
Total maximum size approx. 1.4 MB |
|
|
External Drives |
USB flash drive |
|
|
Connectivity |
Headphones |
Standard stereo phone jack (x 2) |
|
|
MIDI |
IN, OUT |
|
|
AUX IN |
Stereo mini jack |
|
|
AUX OUT |
Standard phone jack (L/L+R, R) |
|
|
USB TO DEVICE |
Type A |
|
|
USB TO HOST |
Type C |
|
|
DC IN |
16 V |
|
|
Sustain Pedal |
Yes (assignable) |
|
|
Pedal Unit |
Yes |
|
|
Amplifiers and Speakers |
Amplifiers |
(20 W + 6 W) x 2 |
|
|
Speakers |
(Oval (12 cm x 6 cm) + 2.5 cm (dome)) x 2 |
|
|
Power Supply |
AC Adaptor |
PA-300C (Output: DC 16 V, 2.4 A) |
|
|
Power Consumption |
18 W (when using PA-300C AC adaptor) |
|
|
Accessories |
Included Accessories |
Owner’s Manual, Online Member Product Registration, Music rest, Foot pedal (FC3A), Power cord*/AC adaptor* (PA-300C) *Varies by area |
|
|
Separately Sold Accessories |
Headphones (HPH-150, HPH-100, HPH-50), Keyboard stand (L-515), Pedal unit (LP-1, FC35), Foot pedal (FC3A), Footswitches (FC4A, FC5), AC adaptor* (PA-300C), USB wireless LAN adaptor (UD-WL01) *Varies by area |
|
|
