Maple neck
The Maple neck provides stability and bright tonal character.
Jatoba Fretboard
Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.
Infinity R H-H pickups
Ibanez Infinity pickups deliver an accurate and tight sound with excellent dynamics. Even under heavy settings, they do not lose tonal clarity.
T106 tremolo bridge
The T106 tremolo bridge with 6 independent saddles makes precise height and intonation adjustment of each string easy.
Mono-unit output jack
The mono-unit output jack is made of solid, durable material and is a single piece to avoid unwanted movement and loosening of the jack, which leads to contact failure or disconnection. This innovation allows for long term playing enjoyment and minimal maintenance.
neck type GRXMaple neck
top/back/body Poplar body
fretboard Jatoba fretboardWhite dot inlay
fret Medium frets
number of frets 22
bridge T106 bridge
string space 10.5mm
neck pickup Classic Elite (H) neck pickupPassive/Ceramic
bridge pickup Classic Elite (H) bridge pickupPassive/Ceramic
factory tuning 1E,2B,3G,4D,5A,6E
string gauge .009/.011/.016/.024/.032/.042
hardware color Chrome
NECK DIMENSIONS
Scale : 648mm/25.5"
a : Width 42mm at NUT
b : Width 57mm at 22F
c : Thickness 19.5mm at 1F
d : Thickness 21.5mm at 12F
Radius : 305mmR
