Super Wizard 5pc Maple/Walnut neck
The Super Wizard 5pc Maple/Walnut neck provides extra-smooth playing.
V7 / S1 / V8 pickups
The RG can dial in any tone, from crystal clear to searing and nasty, thanks to its V7 neck pickup, S1 middle pickup and V8 bridge pickup combination.
Maple fretboard
The Maple fretboard provide crisp, bright highs and strong upper mids.
Edge tremolo bridge
The masterpiece Edge bridge offers exceptional tuning stability, precise intonation adjustment, and playing comfort.
Gotoh® machine heads
Gotoh® machine heads provide super precision, smooth feel, and minimal back lush.
SPECS
neck type Super Wizard5pc Maple/Walnut neck
top/back/body Basswood body
fretboard Maple fretboardBlack dot inlay
fret Jumbo frets
number of frets 24
bridge Edge bridge
string space 10.8mm
neck pickup V7 (H) neck pickupPassive/Ceramic
middle pickup S1 (S) middle pickupPassive/Alnico
bridge pickup V8 (H) bridge pickupPassive/Alnico
factory tuning 1E,2B,3G,4D,5A,6E
strings D'Addario® EXL120
string gauge .009/.011/.016/.024/.032/.042
nut Locking nut
hardware color Black
NECK DIMENSIONS
Scale : 648mm/25.5"
a : Width 43mm at NUT
b : Width 58mm at 24F
c : Thickness 17mm at 1F
d : Thickness 19mm at 12F
Radius : 430mmR
