THE NEW STANDARD
With two available pickup configurations, 5-way switching, and the Focus Switch passive boost, the new Revstar Standard is all about versatility.
The RSS20 features six finish options, a chambered body and carbon-reinforced neck, dual humbucking pickups, 5-way switching, and a passive Focus Switch, providing exceptional versatility.
6 Café racer inspired finishes
Chambered maple and mahogany body
Carbon-reinforced 3-piece mahogany neck
2 Alnico V humbucking pickups
5-Position pickup selector
Passive Focus Switch
Deluxe gig bag included
CHAMBERED BODY WITH ACOUSTIC DESIGN
Revstar Standard guitars feature chambered bodies designed to sculpt tone and reduce weight, with carbon reinforcement in the neck to improve vibration transfer.
5-WAY SWITCHING
With the same 5-way switching as Revstar Professional, the subtle phase shift on positions 2 and 4 offers a fresh take on classic “in-between” sounds.
FOCUS SWITCH
The push/pull Tone control activates a passive boost with an effect similar to overwound pickups—darker highs, increased mids and lows, and an aggressive character.
CHOICE OF PICKUPS
RSS20 and RSS20L feature humbuckers, and RSS02T offers P90-style single-coils. All pickups are custom designed by Yamaha and use Alnico V magnets for powerful tone.
SWITCH ON
The Focus Switch boost on Professional and Standard models, and the Dry Switch filter on Revstar Element, provide even greater versatility.
Construction: Set-in
Scale Length: 24-3/4” (628.6mm)
Body Materials: Top: Maple / Back: Chambered Mahogany
Body Finish: Gloss Polyurethane
Neck Materials: 3-Piece Mahogany, Carbon Reinforcement
Neck Finish: Satin Polyurethane
Fingerboard Materials: Rosewood
Fingerboard Radius: 12" (304.8mm)
Fret wire: Jumbo Stainless steel
Number of frets: 22
Nut materials: PPS
Neck Width @ 0 Fret / 12th Fret: 41.9 / 56.8 mm
Thickness @1st Fret / 12th Fret: 21.0 / 23.9 mm
Neck Pickup: VH5n: Humbucker / Alnico V
Middle Pickup: N/A
Bridge Pickup: VH5b: Humbucker / Alnico V
Controls: Master Volume, Master Tone (Push-Pull, "Focus Switch")
Pickup Switch: 5-Position Lever Switch
Bridge: Tune-O-Matic
Tremolo Arm: N/A
String spacing: 10.5mm
Tailpiece: Stopbar
Tuning Machines: Die-Cast
Pickguard: Swift Blue: 3-Ply Cream, Sunset Burst/Black/Vintage White/Hot Merlot/Flash Green: 3-Ply Black
String gauge: Elixir Nanoweb Light / 0.010-0.046
Case: Gig Bag
Special Features: N/A
